Shipping container dimensions

Every size we sell, inside and out. Work out what fits, then we'll get it to your place.

4.9 ★ from 400+ Google reviews · 11 depots across QLD and northern NSW

20ft standard, interactive 3D Drag to rotate
Length 6.06m
Width 2.44m
Height 2.59m

The short answer

A standard 20ft container is 6.06m long, 2.44m wide and 2.59m high outside. Inside it's 5.88 × 2.34 × 2.385m, about 33m³, and the doors open to 2.33 × 2.265m. A 40ft is twice as long at 12.19m, and high cubes add 30cm of height.

Lengths drawn to scale. Every size is the same 2.44m wide.

  • 6ft 1.83m
  • 8ft 2.44m
  • 10ft 2.99m
  • 20ft 6.06m
  • 40ft 12.19m

Compare every size

Find your size

Length × width × height, in metres. Not sure which one you need? Take the 60 second quiz

Shipping container sizes: outside and inside dimensions, door opening, space and empty weight
Size Outside (m) Inside (m) Door opening (mm) Space (m³) Empty weight (kg) Quote
6ft mini 1.83 × 1.88 × 1.92 1.67 × 1.85 × 1.73 1,616 × 1,526 5.3 600 Quote →
8ft mini 2.44 × 2.26 × 2.26 2.29 × 2.11 × 2.06 2,110 × 1,950 10.0 950 Quote →
10ft 2.99 × 2.44 × 2.59 2.83 × 2.35 × 2.39 2,340 × 2,280 15.9 1,300 Quote →
10ft high cube 2.99 × 2.44 × 2.90 2.84 × 2.35 × 2.70 2,330 × 2,585 18.0 1,350 Quote →
20ft 6.06 × 2.44 × 2.59 5.88 × 2.34 × 2.385 2,330 × 2,265 32.8 2,200 Quote →
20ft high cube 6.06 × 2.44 × 2.90 5.88 × 2.34 × 2.70 2,340 × 2,585 37.5 2,300 Quote →
40ft 12.19 × 2.44 × 2.59 12.03 × 2.35 × 2.39 2,330 × 2,265 67.7 3,700 Quote →
40ft high cube 12.19 × 2.44 × 2.90 12.03 × 2.35 × 2.70 2,340 × 2,585 76.2 3,900 Quote →

Sizes and weights are typical and vary slightly between builds. Last checked 20 October 2026. Source: ABC and manufacturer spec sheets.

20ft

20ft shipping container dimensions

A 20ft container is 6.06 × 2.44 × 2.59m outside and 5.88 × 2.34 × 2.385m inside. That's about 33m³, the go-to size for a home reno or a job site.

  • 10 Australian pallets, two across and five deep, with 10mm to spare
  • A car or small ute, with room down one side
  • The furniture from a two to three bedroom house
Outside
6.06 × 2.44 × 2.59m
Inside
5,880 × 2,340 × 2,385mm
Door opening
2,330 × 2,265mm
Empty weight
About 2,200kg
Max load
About 28,280kg
Max gross weight
30,480kg
Outside width 2.44mOutside height 2.59mDoor opening 2,330mm wideDoor opening 2,265mm high

Front-on: the door opening is smaller than the outside

Inside length 5.88m (wall to doors)Inside width 2.34mDoors10 Australian pallets, 10mm to spare across

Top-down: 10 pallets fit with 10mm to spare across

Outside length 6.06mOutside width 2.44mOutside height 2.59m

Outside length, width and height

40ft high cube

40ft shipping container dimensions

Our standard 40ft is a high cube: 12.19 × 2.44 × 2.90m outside and 12.03 × 2.35 × 2.70m inside, about 76m³. Twice the length of a 20ft, plus the extra height.

  • 20 Australian pallets, two across and ten deep
  • Machinery, hay or a full house move with room to spare
Outside
12.19 × 2.44 × 2.90m
Inside
12.03 × 2.35 × 2.70m
Door opening
2,340 × 2,585mm
Empty weight
About 3,900kg
Max load
About 26,580kg
Max gross weight
30,480kg
Outside width 2.44mOutside height 2.90mDoor opening 2,340mm wideDoor opening 2,585mm high

Front-on: the door opening is smaller than the outside

Inside length 12.03m (wall to doors)Inside width 2.35mDoors20 Australian pallets, two across and ten deep

Top-down: 20 pallets, two across and ten deep

Outside length 12.19mOutside width 2.44mOutside height 2.90m

Outside length, width and height

10ft

10ft container dimensions

2.99 × 2.44 × 2.59m outside, 2.83 × 2.35 × 2.39m inside, about 16m³. Fits where a 20ft won't.

See 10ft containers →

High cube

High cube dimensions

High cube containers are the same footprint as standard containers, but have an additional 30cm height and are used to transport taller items. 2.9m outside, 2.7m inside. You can pick them by the yellow / black tape on the top corners.

See high cubes →

Mini

6ft and 8ft minis

1.83m and 2.44m long, with 5.3m³ and 10m³ inside. Tools and garden gear where space is tight.

See mini containers →

Specialised range

Specialised container dimensions

Same steel box, built for a different job. The outside matches the standard range, but the inside and the doors change.

Container Outside What's different Empty weight (kg) Link
Reefer 20ft and 40ft high cube 6.1 × 2.4 × 2.6m, 12.2 × 2.4 × 2.9m Insulated walls, so it's smaller inside: about 28m³ and 64m³ 3,000 to 4,600 View →
Open top 20ft and 40ft Same as standard A tarp and bows instead of a roof, for crane loading 2,200 to 3,900 View →
Flat rack 20ft and 40ft 6.1 × 2.4m, 12.2 × 2.4m No walls or roof, ends fold down for oversized loads 2,700 to 4,800 View →
Side opening 20ft and 40ft Same as standard or high cube A full side opens, or 2 or 4 sets of side doors 3,670 to 4,200 View →
Platform 20ft and 40ft 6.1 × 2.4 × 0.24m, 12.2 × 2.4 × 0.32m A flat steel base with corner castings 2,000 to 4,500 View →
Pallet wide 40ft high cube 12.2 × 2.5 × 2.9m Wider inside, so Euro pallets fit two across 3,900 View →
Dangerous goods 8ft to 20ft Same as standard or high cube Built and vented for storing hazardous goods 1,405 to 3,670 View →
ISO tank 20ft frame 6.06 × 2.44 × 2.59m A 26,000L stainless steel tank in a 20ft frame 3,600 View →

Weights

How much does a shipping container weigh?

An empty 20ft weighs about 2,200kg and an empty 40ft high cube about 3,900kg. High cubes, steel floors and reefers weigh more.

Empty weight (tare)
2,200kg
What the container weighs on its own, give or take a bit between builds.
Max load (payload)
28,280kg
The most you can put inside it.
Max gross weight
30,480kg
Most loaded moves end up at 8 to 10 tonnes (say you're moving house with all your furniture packed in), but the container is rated to a gross weight of 30t.

Figures shown for a standard 20ft.

Delivery space

How much room do you need for delivery?

Allow a 15m straight run for the truck, 6m of clear space overhead, and 1.2m at the door end so the doors can open.

  • Firm, level ground where it'll sit
  • A 15m straight run for the truck
  • 6m of overhead clearance from trees and power lines
  • 1.2m at the door end so the doors can open
Top-down sketch of a backyard: the container sits against the fence with its doors facing the tilt tray, which has a straight 15 metre run in from the road. A large tree is kept 6 metres clear overhead.FenceRoad20ft containerDoors: 1.2mTilt trayStraight run: 15mTree: keep6m clear overhead
Top-down sketch: doors facing the truck, a straight run in from the road

FAQs

Questions people ask

Can't see yours? Call us on 1300 22 22 66 and we'll sort it.

01 What are the dimensions of a 20ft shipping container?

6.06 × 2.44 × 2.59m outside and 5.88 × 2.34 × 2.385m inside, about 33m³. The doors open to 2,330mm wide and 2,265mm high.

01 What are the inside dimensions of a 40ft container?

Our standard 40ft is a high cube: 12.03m long, 2.35m wide and 2.70m high inside, about 76m³. Standard height 40ft containers (2.39m inside) are rare.

01 How tall is a high cube container?

2.90m outside and about 2.70m inside, 30cm taller than a standard.

01 How much does an empty 20ft container weigh?

About 2,200kg, depending on the build.

01 How many pallets fit in a 20ft container?

10 standard Australian pallets, two across and five deep. There's only 10mm to spare across the width, so they go in one at a time.

01 Are all shipping containers the same width?

Nearly all are 2.44m wide outside. The exception in our range is the pallet-wide 40ft, at 2.5m.

01 What's the difference between a 20ft and a 40ft?

A 40ft is twice as long with double the space. It needs more room for delivery.

01 Can I see the exact container before I buy?

Yes. We photograph every container at the depot and can send you photos of your unit. See the ABC Photo Promise.
